รหัสสินค้า | 3D0012 |
หมวดหมู่ | cnc shield, 3d printer shield, microbit shield, I/O Extension Board |
ราคาปกติ | |
ลดเหลือ | 90.00 บาท |
ลงสินค้า | 7 ส.ค. 2560 |
อัพเดทล่าสุด | 25 พ.ค. 2568 |
คงเหลือ | 0 ชิ้น |
product description:
1, you can use the A4988 / DRV8825, insert the attention to the direction, otherwise it may burn drive.
2, jumpers are hit on the DP position represents 16 segments (4988) or 32 segments (8825).
3, Jm connected to the motor.
4, Jv connected to 5V and 12V-24V power supply
5, Jc E \ S \ D \ G corresponding to the connection on the Enable \ Step \ Dir \ Gnd drive signal output.
